General Specifications
- Film: Standard Super 8 cartridge
- Release period: 1970s
- Country of manufacture: Japan by Canon
Lens & Zoom
- Lens: Canon Zoom Lens
- Focal length: 7.5 – 60 mm
- Maximum aperture: f/1.4
- Optical zoom: 8×
- Focusing: Manual
- Minimum focusing distance: approx. 1.2 m
- Macro function: Yes
- Zoom control: Motorized and manual
- Filter thread: 58 mm
Viewfinder & Display Information
- Type: TTL reflex viewfinder (Single Lens Reflex)
- Diopter correction: Yes
- Viewfinder information:
- Under-exposure / over-exposure indicators
- Film transport indicator
- Exposure information
Exposure & Frame Rates
- Exposure control: Automatic TTL
- Metering system: CdS cell
- ISO Film : Automatic (25/40 ASA & 100/160 ASA)
- Built-in filter: 85A daylight/tungsten filter with switch
- Shooting speeds:
- - 18 fps
- - 24 fps
- Single-frame shooting: Yes
Power Supply
- Alimentation principale : 6 piles AA (1,5 V)
- Alimentation cellule : intégrée (pas de pile mercure séparée)
- Bouton test batterie : Oui
- Moteur : Moteur électrique interne
Connections & Features
- Remote control socket: Yes
- Accessory shoe: Yes
- Flash synchronization socket: Yes
- Film counter: Yes
- Backlight compensation: Yes
- Special features:
- - Macro mode
- - Single-frame shooting
- - Built-in 85A filter
Dimensions & Weight
- Weight: approx. 1.7 kg
- Dimensions: approx. 68 × 198 × 220 mm
- Tripod socket: 1/4”
- Handle: Fixed, with integrated battery compartment
